General
This specification is applicable to electronic communication equipment, POE power supply, and network transmission
Compliant standards: IEEE 802.3af and 802.3bt
The PSE management chip used in this product is IC+ 8002 Use PD and network cables that meet the standards; otherwise, the power output of the device will be affected
Part Number |
Ports |
Speed |
Output Rated power |
Output Rated Current |
Output Voltage |
Input Rated Voltage |
Input Rated Frequency |
Operating Temperature |
Regulatory Standards |
CET301-ZXX5601080SY |
1 RJ45 |
10G |
60.48W |
1.08A |
56V |
100-240V |
50/60HZ |
0-40 ℃ |
CE & CCC IEEE 802.3af & 802.3bt |
Output Voltage and Current
Output Voltage |
Rated Output Current |
Line Regulation |
Load |
Ripple Noise |
Remark |
56V 53.2~58.8V |
1.08A |
±5% |
±5% |
≤300mVpp |
≤300mVpp |
Remark Measurement is done by 20MHz bandwidth oscilloscope and the output paralleled a 0.1uF ceramic capacitor and a 10uF electrolysis capacitor.
Power Supply Frame
¨Wall mount
ýDesk-top
¨Open frame
¨Other
Output Connector
RJ45 +(1,2)(4,5)pins -(3,6)(7,8)pins
DC Wire Specification
Wire Length:/
Input Specification
Input Voltage:90-264Vac
Rated Voltage:100-240Vac.
Input Frequency:47-63Hz.
Rated Frequency:50/60Hz.
Regulatory Standards
Country |
Standard |
State |
Mark |
China/CCC |
GB 17625.1-2022 |
Meet |
|
CE |
EN 62368-1 |
Meet |
|
Mechanical Dimensions
Network Port Connection Mode
