Product Description (≤250 chars): This 56V 0.535A single-port PoE adapter delivers 29.96W, complies with IEEE 802.3af/at (PoE+), and supports 1Gbps data pass-through. It features overcurrent, overvoltage, short-circuit protection with auto-recovery. Wide 90-264Vac input, 5000m altitude rating, and 3-year lifetime at 25°C. Ideal for IP cameras, VoIP phones, and wireless APs. Plug-and-play wall-mount design.
KEYWORDS
PoE Injector 56V Power Supply Gigabit PoE+ 802.3at PoE+ 29.96W Adapter
| Product Name |
56V 0.535A Single-Port PoE Adapter |
| Output Power |
29.96W |
| Output Voltage |
56V (53.2~58.8V) |
| Output Current |
0.535A |
| PoE Standard |
IEEE 802.3af / 802.3at (PoE+) |
| Data Rate |
1 Gbps |
| Input Voltage Range |
90~264Vac (Rated 100~240Vac) |
| Input Frequency |
47~63Hz |
| Max Input Current |
0.8A @100-240Vac full load |
| Inrush Current (Cold Start) |
≤100A @230Vac |
| Ripple & Noise |
≤300mVpp |
| Turn-on Delay Time |
≤5s @230Vac full load |
| Hold-up Time |
≥5ms @230Vac full load |
| Over Current Protection |
0.55~0.8A (auto-recovery) |
| Short Circuit Protection |
Auto-recovery |
| Operating Temperature |
0℃ ~ 40℃ |
| Storage Temperature |
-20℃ ~ +70℃ |
| MTBF |
≥50,000 hours @25°C (SR332) |
| Lifetime |
≥3 years @25°C full load |
| Dielectric Strength |
Primary to Secondary: 3000Vac / 10mA / 60s |
| Insulation Resistance |
≥50MΩ (500Vdc) |
| Altitude |
≤5000m |
| Output Connector |
RJ45 (4,5 pins + / 7,8 pins -) |
| Cooling |
Natural convection |
| Drop Test |
1m onto wood floor, 6 sides |
✨ WHY CHOOSE THIS POE ADAPTER?
Stable 56V Output
29.96W reliable power for long-distance transmission.
Full Gigabit & PoE+
IEEE 802.3af/at compliant, 1Gbps data pass-through.
Multi-Protection
Overcurrent, overvoltage, short-circuit protection + auto-recovery.
Long Life & High Reliability
3-year min. lifetime, 50,000 hrs MTBF @25°C.
Plug-and-Play
Wall-mount design, no config needed, 90-264Vac wide input.
5000m Altitude Ready
Works perfectly in high-altitude deployments.
